Xi10 – Xi20 Series 1251 Three-wheel Electric Forklift
Powered by integrated lithium-ION battery technology, the Linde Xi10–Xi20 Series 1251 electric forklifts provide zero-emission operation and lift capacities from 1.0 to 2.0 tonnes. Their compact, three-wheel layout is engineered for optimal manoeuvrability in light to medium-duty environments.
A 90 V lithium-ION battery ensures consistent output, improving drive and lift motor efficiency by up to 5%. Lifting and lowering speeds are approximately 20% higher than industry norms, enabling the Xi10–Xi20 series to maximise throughput in everyday operations.
Safety functions—including automatic speed reduction and a foot-activated parking brake—provide operators with greater security and control.
Slimline mast, narrow A-pillars, and a lowered front plate provide exceptional visibility.
A low centre of gravity maximises stability and tipping resistance for enhanced safety.
Linde Curve Assist automatically adjusts cornering speed to minimise the risk of tipping.
Overhead tilt cylinders allow precise load handling, even at elevated lift heights.
An automatic parking brake keeps the truck securely in place on ramps and gradients.
Low step-in and a spacious cabin offer generous headroom and legroom for operator comfort.
Linde Load Assist enhances safety during high-lift operations.
Roomy cabin featuring a 3.5-inch display that shows all essential truck information.
Elastomer ring bearings isolate the operator’s workstation, minimising vibration and fatigue.
Twin pedal control combined with Linde Load Control delivers intuitive, smooth operation.
Linde Steer Control provides the option of a mini wheel or joystick for precise and comfortable handling.
Robust 90 V technology delivers reliable performance for continuous multi-shift operations.
Li-ION batteries with plug-and-play capability provide seamless power management.
Side-access design and open chassis allow fast and easy battery changes.
Compact three-wheel layout ensures excellent manoeuvrability in confined spaces.
Powered by dual motors — 2 × 6.5 kW drive motors plus a 13 kW lift motor — for strong, efficient performance.
Effortlessly handles gradients of up to 58 %.
Achieves traction speeds of up to 20 km/h, whether loaded or unloaded.
Service intervals are automatically adjusted according to real-time operating hours.
Remote diagnostics detect wear or damage early, helping to reduce downtime.
Modular components, such as the mast or operator workstation, enable fast and easy replacements.
Extended maintenance intervals — for example, hydraulic oil changes every 6,000 hours — enhance operational efficiency.
Fully enclosed, maintenance-free drive components provide dependable, low-maintenance performance.
